Description

• Integrated lifting handles each tested to 60Kg of direct lift
• Recommended for landscaping and Driveways
• Galvanised tray to BS EN 1461:2009
• Perfect partner for the Clark-Drain 450mm dia chamber & riser part no. CD U453/CD U455
• Moulded grouting flange

• Product Weight: 12kg
• Applications: Driveway loading
• Loading Rating: 10 tonne GPW
• Loading Rating Data: 25kN held for 30 seconds
• FACTA Clauses: 7.0, 7.2, 7.2.1, 7.2.3
• Locking: None
• Cover Material: Mild Steel to EN 10346 2015 DD11
• Frame Material: Polypropylene (Grade AP9)
• Overall Dimensions: 585 x 585 x 88mm
• Clear Opening: 450 diameter
